DIMMER WALL SWITCH BC-USDM101-5-GE
The Bluezone Bluetooth® Dimmer Wall Switch is a direct replacement for your existing wall switch, delivering enhanced lighting control with a single sliding block for quick, intuitive brightness adjustment of your connected Bluezone devices.
Specifications
Action
Bluetooth Dimmer Wall Switch
Actuations
Rated for 50,000 actuations
Power
120-277VAC, 60Hz
Transmission Power
<0.2mW
Max Fixtures Per Control
100
Max Bluetooth Range
120ft (36m)
Interoperability
Bluezone Sensors and Gateways
Operating Temp
-32°F~122°F / 0°C ~ 50°C
Warranty
5 years
IP Rating
IP20
Enclosure
Polycarbonate
Weight
4.69oz (133g)
Color / Finish
white
Wireless Standards
Bluetooth SIG Mesh / BLE 5.0
Radio Frequency
2400-2483.5 MHz
Wireless Range
60 ft. (18 m) radius open range
Mobile App
Bluezone App (IOS /Android)
Encryption
AES-128 bit
Gateway Required
Optional
Documents & downloads
BlueZone-Spec-Sheet-BC-USDM101-5-GE-DIMMER-WALL-SWITCH
PDF · 382 KB
Instruction-BC-USDM101-5-GE
PDF · 2 MB
Need help commissioning this product?
Our team supports you from spec to install.
