PASSIVE INFRARED SENSOR BRI-DT301P-BLE-GE
The low-profile BRI-DT301P-BLE-GE sensor uses passive infrared (PIR)
technology with Bluetooth® connectivity, mounting flush to the ceiling
for a flat, unobtrusive appearance while delivering 360° coverage and
convenient wireless control.
Specifications
Motion Sensor
Passive infrared sensor
Input Power
120/230 (single phase)/277/347 VAC,50/60 HZ
Control Output
N/A
HF System
N/A
Transmission Power
<0.2mW
Mounting Height
12ft (4m) Max.
Detection Angle
360°
Operating Temperature
-32°F~+131°F(0°C~+55°C)
IP Rating
IP20
Max Bluetooth Range
150ft (40m)
Warranty
5 years
Weight
5.256 oz (149g)0.
Color / Finish
White
Enclosure Material
Polycarbonate
Wireless Standard
Bluetooth SIG Mesh / BLE 5.0
Mesh Range (node-to-node / commissioning)
100ft/50ft
Encryption
AES 128-bit
Mobile App
Bluezone App (IOS /Android)
Gateway Required
Optional
Documents & downloads
Instruction-BRI-DT301P-BLE-GE
PDF · 1 MB
BlueZone-Spec-Sheet-BRI-DT301P-BLE-GE-BLUETOOTH-PIR-SENSOR
PDF · 428 KB
